Lavalle - PVC Interlocking floor tiles

Lavalle tiles bring life to your floors. Lavalle tiles are specifically designed for factory/workshop floors where lot of foot/trolley/vehicle movements happen. In these work environments, the floors are prone to damages and the average life expectancy is less than two years. Lavalle tiles withstand high pressure and torque from vehicle/fork lift wheels. Lavalle tiles are flexible in nature, so they can absorb weight impacts. Lavalle tiles are interlocked to each other, so it works as a floor carpet. Lavalle tiles are not fixed to the underlying floor permanently. So, in case of a factory relocation or a change in the floor layout, the tiles can be easily dismantled and reused.

Your investment on Lavalle tile is never lost even if you decide to relocate. The life expectancy of Lavalle tile is at least 3 to 5 times more, compared to other industrial flooring solutions. Lavalle tiles come in red, green, blue, grey and black colors. We maintain a team of professionals who can travel to your plant location and do the laying work of Lavalle tiles.

video popup bg image

Physical Specifications

  • 1 PVC Tile = 2.25 Sq.ft.
  • Weight : 1.24Kg -1.26Kg
  • Elongation rate : 280%
  • Tear strength : 30kgf/cm
  • Tensile strength : 2.80 kg/cm2
  • Hardness (shore D) : 70 (ASTM D 2240)
  • Density : 1.38 - 1 .46 gm/cc (ASTM D 792)
  • Sulphated ash content : 20.04 (IS 12235 Pt. 17)
  • Dimensions : Length : 464 mm; Width : 464 mm; Thickness : 5 mm
  • Water resistance : No change of discoloration and deterioration observed
  • Acid resistance (Sulphuric acid) : No change of discoloration and deterioration observed for dilute sulphuric acid (with 10% and 50 % concentration). But, discolouration and deterioration was observed for concentrated sulphuric acid.
  • Alkali resistance (Sodium Hydroxide) : No change of discoloration and deterioration observed.

Advantages of PVC Tiles

  • Hygienic
  • Attractive
  • Slip-resistant
  • Easy & quick to install
  • Provides insulation
  • Can be loose laid with minimal floor preparation
  • Can withstand frequent forklift / vehicle / foot movement

Characteristics

Noise reduction

PVC tile with a weight of 1.28Kg and density of 1.38-1.46 gm/cc ensures high level of noise reduction.

Fire & Cigarettes

PVC Tile passed the Hot Metal Nut test. PVC tiles catch fire if exposed to welding arc for more than a minute or so.

Wear & Tear

PVC Tiles have been tested by the Tetrapod method. After 3,000,000 cycles, there were no visible changes in the surface texture.
